Engineered for Performance, Designed for Resilience
Two compute tiers. Two storage models. One design principle:
performance where it matters, affordability where it fits,
and predictable recovery backed by a strict 50% maximum-provisioning ceiling.
MCC (Gen4)GPC (Gen3)Proxmox VECeph + HPE Alletra
Inside the Cloud Propeller Platform
Cloud Propeller is a purpose-built enterprise cloud
that favors predictability over scale.
What runs beneath the VMs matters. This page
walks through the layers of Cloud Propeller’s
platform architecture: Proxmox VE
at the foundation, the
host architecture with data, control,
and storage planes distributed across four NICs for
layered redundancy, and the compute and storage tiers
that deliver two distinct price/performance options
under one shared design philosophy.
Hypervisor Foundation
After Nine Years on VMware, We Rebuilt on Something Better
For Cloud Propeller’s first nine years, every
host we operated ran VMware ESXi. In
mid-2024, just a few months
after Broadcom’s acquisition of VMware, we
set ESXi aside and re-tested every serious
hypervisor platform on the market. What followed
was a twelve-month evaluation
across raw performance, operational behavior under
load, licensing economics, and day-to-day operator
experience — the kind of test cycle most
providers never run unless they are forced to
come up with a new solution.
Proxmox VE emerged as the clear
winner — not just in our testing, but in the
real-world test workloads our clients helped
validate.
One of Cloud Propeller’s core differentiators
has always been our focus on
high-frequency CPU performance over
hyperscale-style density. When we built our
previous-generation platform (Gen3), now serving as
our
General Purpose Compute (GPC)
tier, we chose
Intel® Xeon® Gold 6246R
processors because they delivered an unusually high
3.4 GHz base clock for a
16-core server CPU — exactly the kind of
per-core performance profile we wanted, while still
keeping core counts practical under VMware’s
core-based licensing model.
The move to Proxmox VE came at exactly the right
time. As we were designing our next-generation
Mission Critical Compute (MCC)
platform, Intel introduced the kind of
processor we had been waiting for: the
Intel® Xeon®6745P,
a 32-core, all-performance-core CPU capable of
running at a 3.6 GHz base clock
in Intel®SST-PP
compute-optimized mode. In the server world, that combination is
exceptional: high core count without giving up high
base frequency. VMware’s per-core licensing
would have penalized that choice precisely because
it delivered more cores. Proxmox VE turned that
equation around, letting us choose the CPU
architecture we actually wanted.
That combination — Proxmox VE’s
licensing model and the 6745P’s performance
profile — lets our MCC platform deliver
exceptional per-core performance, more total
compute headroom, and better economics without
falling back to slower, density-first CPU choices
designed around provider consolidation instead of
client performance.
On top of that foundation, our
Cloud Manager portal,
based on MultiPortal, gives clients a
cleaner single pane of glass for everyday cloud
operations: faster provisioning, simpler VM lifecycle
management, clearer resource visibility, and a more
agile operating experience than the legacy VMware
Cloud Director model allowed.
Host Architecture
Four NICs, Three Planes, One Design
Every Cloud Propeller host has four NICs —
deliberately wired so the busiest, most critical
traffic gets the most bandwidth and fault-tolerance,
and any failure that does occur stays small,
bounded, and predictable by design.
Both of our Platforms,
Mission Critical Compute (MCC)
and General Purpose Compute (GPC),
are wired identically. What differs between them
(besides compute)
is NIC speed (100 Gbps vs. 10 Gbps),
and primary storage (Ceph vs. iSCSI).
The first two NICs are bonded into bond0,
an LACP/MLAG across two Arista DCS-7060CX2-32S
top-of-rack switches.
Bond0 carries the most critical and busiest traffic
on the host — VM tenant data, the Management
VLAN and Cluster Heartbeat Ring 0, and (on MCC) the
Ceph Public VLAN — all on the same
high-bandwidth, dual-NIC fault-tolerant path.
Third and fourth NICs are unbonded. NIC 3
carries a second Management VLAN, Cluster Heartbeat
Ring 1, and iSCSI Fabric A, and NIC 4 is in
charge of Cluster Heartbeat Ring 2 and iSCSI Fabric B.
On MCC,
Ceph
is the production storage. The Ceph Public VLAN
rides bond0; the
Ceph Private VLAN, used for OSD↔OSD
replication, rides NIC 4. If NIC 4 drops,
replication and backfill on that node stop and its
OSDs are marked degraded until the link returns,
however, production I/O on bond0 keeps running
because Ceph Public traffic is unaffected. iSCSI Fabrics A and B
are wired and available, but reserved as tier-2
(optional).
On GPC, iSCSI is
the active and only storage path — multipathed
across both fabrics to the
HPE Alletra SAN. Ceph
isn’t deployed; NIC 4 simply carries
Cluster Heartbeat Ring 2 and iSCSI Fabric B.
Conceptually, we have three intentional
traffic planes sharing NICs by
design: a data plane on bond0,
a control plane spread across all
four NICs, and a storage plane
on bond0 for Ceph, and NICs 3 and 4 for iSCSI.
Our clusters are designed to
tolerate the loss of any physical NIC (both ports),
any optic, or even an entire top-of-rack switch
— and continue to function as if nothing had
happened.
Bonded Tenant Data Path
bond0 — 2 NICs in LACP/MLAG across two Arista ToRs
Carries VM data, mgmt, cluster ring 0, Ceph Public VLAN
MCC and GPC are powered by the same hypervisor, have
similar host architecture, and ride over the same
network fabric. Silicon, memory, storage architecture,
and host networking are the levers that differentiate
them.
Hardware Comparison
MCC vs GPC, side by side
Specification
Gen 4MCCMission Critical Compute
Gen 3GPCGeneral Purpose Compute
Platform generation
4th Generation Cloud Propeller Architecture
6th-gen Intel® Xeon® Family
3rd Generation Cloud Propeller Architecture
2nd-gen Intel® Xeon® Scalable Family
Hypervisor
Proxmox VE 9.1.x(KVM + LXC, native Linux)
CPU
Intel® Xeon®6745P(Granite Rapids, “P”-variant high-clock, all performance cores — no efficiency or low-priority cores) — Two CPUs per host
Intel® Xeon® Gold 6246R(Cascade Lake Refresh, all performance cores — no efficiency or low-priority cores) — Two CPUs per host
CPU speed
32 cores @ 3.6 GHz base (running in SST-PP compute-optimised mode, 4.1 GHz max turbo)
Storage defines how a cloud platform behaves under
pressure. We take two different paths between the
tiers — both fast under load, both engineered to
keep tenant I/O running through hardware failures.
Our Mission Critical Compute
(MCC) platform
runs all-flash NVMe
Ceph
with triple-mirror replication across the cluster.
There is no central storage controller to fail and no
RAID rebuild window to wait through — if a disk
or even an entire host disappears, Ceph re-replicates
the missing copies onto remaining capacity in the
background while tenant I/O keeps running.
Capacity, throughput, and parallel client count all
scale with cluster size — adding NVMe hosts
grows the three together, with no central controller
to bottleneck later. Each of our MCC
hosts contains 12 × 15 TB Kioxia CM-7
enterprise NVMe SSDs and contributes 180 TB raw
to the underlying cluster. Public I/O (tenant
data) rides the
200 Gbps MLAG,
while private I/O (back-end OSD↔OSD
replication) runs on its own dedicated 100 Gbps
NIC — isolating tenant traffic from
replication storms so neither can crowd the other.
Our General Purpose Compute
(GPC) platform
runs on
HPE Alletra
(aka Nimble) NVMe SAN over iSCSI — mature enterprise storage
with redundant controllers and triple+ parity
protection. The recovery model is different
(controller failover plus parity reconstruction) but
the operational behavior is the same predictable,
well-understood pattern enterprise storage teams
already know and trust.
Alletra’s controller pair runs active/passive
— one controller serves I/O at the full
200 Gbps front-end (8 × 25 Gbps) while the
other stands by, ready to take over. Any
active-controller fault triggers automated failover
in under 18 seconds, with multipath drivers
transparently rerouting I/O to the standby. HPE’s InfoSight platform watches the
array’s behavior in production and surfaces
the failure modes that matter before they impact
tenant I/O.
Every cluster — MCC and GPC, Pay As You Go and
Dedicated — is capped at 50% of
its design capacity. Not as an aspirational target. As an
actual line we do not cross.
Hyperscalers can get away with aggressive
over-provisioning because, at their scale, spare capacity
and noisy neighbors get averaged out statistically across
enormous fleets. But that does not mean every individual
workload gets a clean host, consistent neighbors, or
predictable performance. Anyone who has rebooted an
instance hoping to land on better underlying hardware
understands the difference.
We do not operate at that scale, and we do not want to.
Instead, we buy headroom into the design: a 50% ceiling
means a host losing a peer does not tip anyone into
contention, a maintenance window does not concentrate
load, and an unexpected burst has room to breathe.
That headroom is what makes Cloud Propeller feel
hyperscale to our own clients. A workload can double
overnight — and in real cases, we have had clients
grow many times beyond their original footprint within a
span of just a few days — without our platform
running into a capacity wall of any kind. The room is
already built in.
It is more expensive to operate infrastructure with this
much headroom, but it also means the platform behaves
the way it was architected — under load, during
maintenance, and in the worst five minutes of the worst
day of the year.
